GS-3012F User’s Guide
Link Aggregation 14-5
Table 14-2 Link Aggregation: Configuration
LABEL DESCRIPTION
Dynamic (LACP) Select this check box to enable LACP for a trunk.
Port This field displays the port number.
Group Select the trunk group to which a port belongs.
LACP Timeout Timeout is the time interval between the individual port exchanges of LACP packets in order to
check that the peer port in the trunk group is still up. If a port does not respond after three tries,
then it is deemed to be “down” and is removed from the trunk. Set a short timeout (one second)
for busy trunked links to ensure that disabled ports are removed from the trunk group as soon as
possible.
Select either 1 second or 30 seconds.
Apply Click Apply to save your changes back to the switch.
Cancel Click Cancel to begin configuring this screen afresh.
