GS-3012F User’s Guide
Queuing Method 18-3
LABEL DESCRIPTION
Port This label shows the port you are configuring.
Method Select SPQ (Strict Priority Queuing) or WRR (Weighted Round Robin Scheduling).
Strict Priority Queuing (SPQ) services queues based on priority only. When the highest priority
queue empties, traffic on the next highest-priority queue begins. Q7 has the highest priority and
Q0 the lowest.
WRR services queues on a rotating basis based on their queue weight (the number you
configure in the queue Weight field). Queues with larger weights get more service than queues
with smaller weights.
Weight When you select WRR, enter the queue weight here. Bandwidth is divided across the different
traffic queues according to their weights. Queues with larger weights get more service than
queues with smaller weights.
Apply Click Apply to save your changes back to the switch.
Cancel Click Cancel to begin configuring this screen afresh.
