GS-3012F User’s Guide
4-4 Introducing the Web Configurator
Table 4-2 Web Configurator Screen Sub-links Details
BASIC SETTING ADVANCED
APPLICATIONS
ROUTING PROTOCOL MANAGEMENT
802.1x
Port Security
Access Control
SNMP
Logins
Service Access Control
Remote Management
Queuing Method
Classifier
Policy Rule
DHCP Relay
The following table summarizes these sub-links in the navigation panel.
Table 4-3 Navigation Panel Sub-link Descriptions
LABEL DESCRIPTION
Basic Setting Screens
System Info This link takes you to a screen that displays general system and hardware monitoring
information.
General Setup This link takes you to a screen where you can configure general identification information
about the switch.
Switch Setup This link takes you to a screen where you can set up global switch parameters such as
VLAN type, MAC address learning, IGMP snooping, GARP and priority queues.
IP Setup This link takes you to a screen where you can configure the IP address, subnet mask
(necessary for switch management) and DNS (domain name server).
Port Setup This link takes you to screens where you can configure settings for individual switch ports.
Advanced Application
VLAN This link takes you to screens where you can configure port-based or 802.1Q VLAN
(depending on what you configured in the Switch Setup menu).
Static MAC
Forwarding This link takes you to screens where you can configure static MAC addresses for a port.
These static MAC addresses do not age out.
Filtering This link takes you to a screen to set up filtering rules.
Spanning Tree
Protocol
This link takes you to screens where you can configure the STP to prevent network loops.
Bandwidth Control This link takes you to screens where you can cap the maximum bandwidth allowed from
specified source(s) to specified destination(s).
Broadcast Storm
Control
This link takes you to a screen to set up broadcast filters.
Mirroring This link takes you to screens where you can copy traffic from one port or ports to another
port in order that you can examine the traffic from the first port without interference
