GS-3012F User’s Guide
Hardware Connections
3-7
Table 3-2 Front Panel LED Descriptions
LED COLOR
STATUS
DESCRIPTION
On
The link to a 10 Mbps Ethernet network is up.
Off
The link to an Ethernet network is down.
FDX
Amber
On
The Gigabit port is negotiating in full-duplex mode.
Off
The Gigabit port is negotiating in half-duplex mode and no collisions are
occurring.
MGMT
10
Green Blinking The system is transmitting/receiving to/from an Ethernet device.
On
The port is connected at 10Mbps.
Off
The port is not connected at 10Mbps or to an Ethernet device.
100
Amber Blinking The system is transmitting/receiving to/from an Ethernet device.
On
The port is connected at 100Mbps.
Off
The port is not connected at 100Mbps or to an Ethernet device.
3.5 Configuring the GS-3012F
You may use the embedded web configurator or command line interface to configure the switch. If you’re using the
web configurator, you need Internet Explorer 5.5 and later or Netscape Navigator 6 and later.
You can access the command line interface using a terminal emulation program on a computer connected to the
switch console port (see Section 3.2.1) or access the switch using Telnet.
You can use the “config save” command to save 802.1Q, STP, Cluster and IP configuration
changes to non-volatile memory (Flash). These changes are effective after you restart the switch.
However you cannot use “config save” for all other line command configurations. These are
saved in volatile memory (DRAM), so are not effective after you restart the switch.
The next part of this guide discusses configuring the switch using the web configurator.
