TMS320C6202
FIXED-POINT DIGITAL SIGNAL PROCESSOR
SPRS072B – AUGUST 1998 – REVISED AUGUST 1999
72
POST OFFICE BOX 1443
•
HOUSTON, TEXAS 77251–1443
MECHANICAL DATA
GJL (S-PBGA-N352)
PLASTIC BALL GRID ARRAY
25,00 TYP
0,50
AC
W
U
AA
AE
R
N
L
J
G
E
A
C
26
22
20
16
12 14
18
10
8
6
2
Seating Plane
4
4173516-2/C 07/99
24
1
3
5
7
9
11 13 15 17 19 21 23 25
SQ
26,80
27,20
Y
V
P
H
K
M
F
D
B
T
SQ
24,80
25,20
16,30 NOM
See Note E
0,60
0,40
0,70
0,50
Heat Slug
1,00 NOM
AB
AD
AF
3,50 MAX
0,50
16,30 NOM
1,00
0,15
1,00
M
∅
0,10
NOTES: A. All linear dimensions are in millimeters.
B. This drawing is subject to change without notice.
C. Thermally enhanced plastic package with heat slug (HSL).
D. Flip chip application only
E. Possible protrusion in this area, but within 3,50 max package height specification
F. Falls within JEDEC MO-151/AAL-1
thermal resistance characteristics (S-PBGA package)
NO
°
C/W
Air Flow LFPM†
1
R
Θ
JC
Junction-to-case
0.47
N/A
2
R
Θ
JA
Junction-to-free air
14.2
0
3
R
Θ
JA
Junction-to-free air
12.3
100
4
R
Θ
JA
Junction-to-free air
10.2
250
5
R
Θ
JA
Junction-to-free air
8.6
500
† LFPM = Linear Feet Per Minute
