Signal Descriptions (Continued)
SIGNAL PIN NO.
TYPE† DESCRIPTION
NAME GJL GLS
TYPE† DESCRIPTION
MULTICHANNEL BUFFERED SERIAL PORT 2 (McBSP2)
CLKS2 R3 N1 I External clock source (as opposed to internal)
CLKR2 T2 N2 I/O/Z Receive clock
CLKX2 R4 N3 I/O/Z Transmit clock
DR2 V1 R2 I Receive data
DX2 T4 R1 O/Z Transmit data
FSR2 U2 P3 I/O/Z Receive frame sync
FSX2 T3 P2 I/O/Z Transmit frame sync
RESERVED FOR TEST
RSV0 L3 J2 I Reserved for testing, pullup with a dedicated 20-k
Ω
resistor
RSV1 G3 E3 I Reserved for testing, pullup with a dedicated 20-k
Ω
resistor
RSV2 A12 B11 I Reserved for testing, pullup with a dedicated 20-k Ω resistor
RSV3 C15 B13 O Reserved (leave unconnected, do not connect to power or ground)
RSV4 D12 C10 O Reserved (leave unconnected, do not connect to power or ground)
SUPPLY VOLTAGE PINS
A11 A3
A16 A7
B7 A16
B8 A20
B19 D4
B20 D6
C6 D7
C10 D9
C14 D10
C17 D13
DVDD C21 D14 S 3.3-V supply voltage
G4 D16
G23 D17
H3 D19
H24 F1
K3 F4
K24 F19
L1 F22
L26 G4
N24 G19
P3 J4
† I = Input, O = Output, Z = High Impedance, S = Supply Voltage, GND = Ground
ADV
ANCE INFORMA
