TMS320C6202
FIXED-POINT DIGITAL SIGNAL PROCESSOR
SPRS072B – AUGUST 1998 – REVISED AUGUST 1999
12
POST OFFICE BOX 1443
•
HOUSTON, TEXAS 77251–1443
Signal Descriptions (Continued)
SIGNAL PIN NO.
TYPE† DESCRIPTION
NAME GJL GLS
TYPE† DESCRIPTION
EXPANSION BUS
XCLKIN A9 C8 I Expansion bus synchronous host interface clock input
XFCLK B9 A8 O Expansion bus FIFO interface clock output
XD31 D15 C13
XD30 B16 A13
XD29 A17 C14
XD28 B17 B14
XD27 D16 B15
XD26 A18 C15
XD25 B18 A15
XD24 D17 B16
XD23 C18 C16
XD22 A20 A17
XD21 D18 B17
XD20 C19 C17
Expansion bus data
XD19 A21 B18
Ex ansion bus data
•
Used for transfer of data, address, and control
XD18 D19 A19
, ,
•
Also controls initialization of DSP modes and expansion bus at reset via pullup/pulldown
i t
XD17 C20 C18
resistors
– XCE[3:0] memory type
XD16 B21 B19
I/O/Z
– XCE[3:0] memory ty e
– XBLAST polarity
XD15 A22 C19
I/O/Z
y
– XW/R polarity
A h h h t ti
XD14 D20 B20
– Asynchronous or synchronous host operation
– Arbitration mode (internal or external)
XD13 B22 A21
– Arbitration mode (internal or external)
– FIFO mode
XD12 E25 C21 – Little endian/big endian
Boot mode
XD11 F24 D20
– Boot mode
XD10 E26 B22
XD9 F25 D21
XD8 G24 E20
XD7 H23 E21
XD6 F26 D22
XD5 G25 F20
XD4 J23 F21
XD3 G26 E22
XD2 H25 G20
XD1 J24 G21
XD0 K23 G22
XCE3 F2 D2
XCE2 E1 B1
O/Z
Expansion bus I/O port memory space enables
•
Enabled by bits 28 29 and 30 of the word address
XCE1 F3 D3
O/Z •
Enabled by bits 28, 29, and 30 of the word address
• Only one asserted during any I/O port data access
XCE0 E2 C2
• Only one asserted during any I/O ort data access
† I = Input, O = Output, Z = High Impedance, S = Supply Voltage, GND = Ground
