TMS320C6202
FIXED-POINT DIGITAL SIGNAL PROCESSOR
SPRS072B – AUGUST 1998 – REVISED AUGUST 1999
53
POST OFFICE BOX 1443
•
HOUSTON, TEXAS 77251–1443
EXPANSION BUS SYNCHRONOUS HOST PORT TIMING (CONTINUED)
BE
AD D1 D2 D3 D4
13
13
12 11
10
9
8
7
6
5
4 4
3
3
2 2
1
1
XCLKIN
XAS
XW/R†
XW/R†
XBLAST‡
XBE[3:0]/XA[5:2]§
XD[31:0]
XRDY
XWE/XWAIT¶
† XW/R input/output polarity selected at boot
‡ XBLAST output polarity is always active low.
§ XBE[3:0]/XA[5:2] operates as byte enables XBE[3:0] during host-port accesses.
¶ XWE/XWAIT operates as XWAIT output signal during host-port accesses.
Figure 33. ’C6202 as Bus Master—Read
Addr D1 D2 D3 D4
13
13
12 11
8
7
6
5
4 4
3
3
2 2
1
1
XCLKIN
XAS
XW/R†
XW/R†
XBLAST‡
XBE[3:0]/XA[5:2]§
XD[31:0]
XRDY
XWE/XWAIT¶
† XW/R input/output polarity selected at boot
‡ XBLAST output polarity is always active low.
§ XBE[3:0]/XA[5:2] operates as byte enables XBE[3:0] during host-port accesses.
¶ XWE/XWAIT operates as XWAIT output signal during host-port accesses.
Figure 34. ’C6202 as Bus Master—Write
