Dimensions
and Weights
PKG-PRC002-EN 94
Weights
Table W-1. Unit Weights - SCWF/SCRF/SIWF/SIRF
2-Row 4-Row
Unit Base Airside Waterside Waterside Heating
Size Weight Economizer Economizer Economizer Coil Box
lbs. (kg) lbs. (kg) lbs. (kg) lbs. (kg) lbs. (kg)
SCWF/SIWF 20 3010 (1365) 430 (195) 140 (65) 340 (155) 460 (210)
22 3010 (1365) 430 (195) 140 (65) 340 (155) 460 (210)
25 3080 (1400) 430 (195) 140 (65) 340 (155) 460 (210)
29 3300 (1500) 500 (225) 190 (85) 390 (175) 460 (210)
32 3490 (1585) 500 (225) 190 (85) 390 (175) 460 (210)
35 3610 (1640) 500 (225) 280 (130) 505 (230) 460 (210)
38 3710 (1685) 500 (225) 280 (130) 505 (230) 460 (210)
42 4560 (2070) 640 (290) 255 (115) 505 (230) 600 (270)
46 4650 (2110) 640 (290) 255 (115) 505 (230) 600 (270)
52 4970 (2255) 700 (315) 335 (150) 665 (300) 600 (270)
58 5220 (2365) 700 (315) 335 (150) 665 (300) 600 (270)
65 5430 (2465) 800 (360) 335 (150) 665 (300) 600 (270)
72 5550 (2520) 800 (360) 335 (150) 665 (300) 600 (270)
80 5940 (2695) 800 (360) 335 (150) 665 (300) 600 (270)
SCRF/SIRF 20 2920 (1325) 430 (195) 140 (65) 340 (155) 460 (210)
25 3140 (1425) 500 (225) 190 (85) 390 (175) 460 (210)
29 3330 (1510) 500 (225) 190 (85) 390 (175) 460 (210)
30 3370 (1530) 500 (225) 280 (130) 505 (230) 460 (210)
35 3470 (1575) 500 (225) 280 (130) 505 (230) 460 (210)
40 4410 (2000) 640 (290) 255 (115) 505 (230) 600 (270)
50 4980 (2260) 700 (315) 335 (150) 665 (300) 600 (270)
60 5620 (2550) 800 (360) 335 (150) 665 (300) 600 (270)
Notes:
1. All unit weights include refrigerant, water, inlet guide vanes and controllers, electric heat and valves.
2. Add 150 lbs. to total weight to obtain approximate shipping weight.
3. Flexible horizontal discharge plenum option weights:
45-inch plenum = 705 lbs.
Standard height plenum = 430 lbs.
Low height plenum = 325 lbs.
Table W-2. Unit Weights - CCRC/CIRC
Shipping Operating
Unit Weight Weight
Size lbs (kg). lbs.(kg)
CCRC/CIRC 20 2030 (920) 1906 (865)
CCRC/CIRC 29 2084 (945) 1960 (890)
CCRC/CIRC 32 2138 (970) 2014 (915)
CCRC/CIRC 35 3018 (1370) 2833 (1285)
CCRC/CIRC 40 3072 (1395) 2887 (1310)
CCRC/CIRC 50 3995 (1810) 3695 (1675)
CCRC/CIRC 60 4275 (1940) 3975 (1805)
Table W-3. Variable Frequency Drive Weights
Motor HP Voltage
Weight
lbs. (kg)
7.5 200V 26 (12)
7.5 460V 15 (7)
10 200V 26 (12)
10 460V 26 (12)
15 200V 75 (34)
15 460V 26 (12)
20 200V 75 (34)
20 460V 31 (14)
25 200V 126 (57)
25 460V 75 (34)
30 200V 126 (57)
30 460V 75 (34)
40 200V 126 (57)
40 460V 75 (34)
50 460V 126 (57)
