Performance

Water-Cooled

Data

PKG-PRC002-EN

54

65 Ton

Table PD-35. SCWF/SIWF 65 - Economizer Full Capacity - 26,000 cfm

Entering Water Temp

Entering Air

45 F

55 F

EDB

EWB

Flow

Total

Sensible

LWT

Total

Sensible

LWT

F

F

gpm

MBh

MBh

F

MBh

MBh

F

163

644.4

590.0

52.9

407.4

407.4

60.0

62

195

670.0

600.7

51.9

417.5

417.5

59.3

226

689.7

609.0

51.1

424.7

424.7

58.8

163

815.9

497.6

55.0

472.6

370.1

60.8

75

67

195

863.7

516.4

53.9

495.9

378.4

60.1

226

899.9

530.8

53.0

514.5

385.0

59.6

163

1043.3

413.8

57.8

676.7

285.8

63.3

72

195

1106.7

436.7

56.4

720.4

300.4

62.4

226

1155.0

454.5

55.2

753.5

311.5

61.7

163

710.6

695.5

53.7

509.0

509.0

61.2

62

195

730.5

715.4

52.5

521.6

521.6

60.3

226

745.5

730.4

51.6

530.5

530.5

59.7

163

830.6

636.1

55.2

522.6

520.8

61.4

80

67

195

872.3

652.6

53.9

540.3

527.1

60.5

226

904.5

665.4

53.0

553.9

532.0

59.9

163

1041.0

546.6

57.8

676.9

419.8

63.3

72

195

1104.0

569.9

56.3

718.5

433.6

62.4

226

1152.2

588.1

55.2

750.9

444.5

61.6

163

809.6

809.6

54.9

610.6

610.6

62.5

62

195

829.9

829.9

53.5

625.5

625.5

61.4

226

844.4

844.4

52.5

636.1

636.1

60.6

163

867.7

783.1

55.6

612.4

612.4

62.5

85

67

195

903.1

797.2

54.3

627.4

627.4

61.4

226

930.4

808.2

53.2

638.2

638.2

60.6

163

1043.6

680.9

57.8

701.3

561.3

63.6

72

195

1103.6

703.1

56.3

736.1

573.0

62.5

226

1149.9

720.5

55.2

763.4

582.1

61.8

Table PD-36. SCWF/SIWF 65 - Economizer Low Capacity - 26,000 cfm

Entering Water Temp

Entering Air

45 F

55 F

EDB

EWB

Flow

Total

Sensible

LWT

Total

Sensible

LWT

F

F

gpm

MBh

MBh

F

MBh

MBh

F

163

420.9

405.9

50.2

278.1

278.1

58.4

62

195

436.1

433.3

49.5

285.8

285.8

57.9

226

448.0

438.2

49.0

291.4

291.4

57.6

163

531.1

347.9

51.5

304.3

266.3

58.7

75

67

195

559.7

358.7

50.7

317.8

271.0

58.3

226

581.7

367.0

50.1

329.0

274.9

57.9

163

678.2

274.0

53.3

440.0

194.2

60.4

72

195

715.9

287.3

52.3

464.9

202.3

59.8

226

744.8

297.6

51.6

484.1

208.5

59.3

163

482.5

482.5

50.9

347.6

347.6

59.3

62

195

496.2

496.2

50.1

357.2

357.2

58.7

226

506.4

506.4

49.5

364.2

364.2

58.2

163

535.3

453.2

51.6

348.2

348.2

59.3

80

67

195

561.0

463.0

50.8

358.2

342.1

58.7

226

581.3

470.7

50.1

365.8

349.7

58.2

163

676.7

377.8

53.3

438.6

298.1

60.4

72

195

714.3

391.0

52.3

463.4

306.1

59.8

226

743.2

401.3

51.6

482.5

312.3

59.3

163

551.5

551.5

51.8

417.1

417.1

60.1

62

195

567.1

567.1

50.8

428.5

428.5

59.4

226

578.6

578.6

50.1

436.9

436.9

58.9

163

564.7

547.6

51.9

417.9

417.9

60.1

85

67

195

585.6

575.9

51.0

429.3

429.3

59.4

226

602.0

582.2

50.3

437.7

437.7

58.9

163

675.3

481.4

53.3

450.5

406.1

60.5

72

195

712.8

494.6

52.3

470.8

412.7

59.8

226

741.5

504.8

51.6

486.9

417.9

59.3
