Dimensions
and Weights
PKG-PRC002-EN
87
Plenum Dimensions - English - (inches)
A
B
C
Weight
Low
64
7
/
8
24
5
/
8
95
7
/
8
325 lbs.
Unit Sizes 20-38 Std.
64
7
/
8
32
3
/
8
95
7
/
8
430 lbs.
Ext.
64
7
/
8
45
95
7
/
8
705 lbs.
Low
80
3
/
8
21
1
/
8
119
7
/
8
390 lbs.
Unit Sizes 42-80 Std.
80
3
/
8
28
5
/
8
119
7
/
8
540 lbs.
Ext.
80
3
/
8
45
119
7
/
8
705 lbs.
Plenum Dimensions - Metric - (mm)
A
B
C
Weight
Low
1648
625
2435
147.4 kg
Unit Sizes 20-38 Std.
1648
822
2435
195.0 kg
Ext.
1648
1143
2435
320.0 kg
Low
2042
537
3045
176.9 kg
Unit SizesI 42-80 Std.
2042
727
3045
244.9 kg
Ext.
2042
1143
3045
320.0 kg
Flexible Horizontal
Discharge Plenum
B
C
A
Flexible Horizontal
Discharge Plenum
