Performance

Water-Cooled

Data

PKG-PRC002-EN

58

80 Ton

Table PD-41. SCWF/SIWF 80 - Economizer Full Capacity - 29,800 cfm

Entering Water Temp

Entering Air

45 F

55 F

EDB

EWB

Flow

Total

Sensible

LWT

Total

Sensible

LWT

F

F

gpm

MBh

MBh

F

MBh

MBh

F

200

719.8

663.3

52.2

456.0

456.0

59.6

62

240

746.6

674.5

51.2

466.7

466.7

58.9

248

751.3

676.5

51.1

468.4

468.4

58.8

200

915.9

559.9

54.2

527.8

416.0

60.3

75

67

240

966.0

579.6

53.1

552.8

424.9

59.6

248

974.5

583.0

52.9

557.1

426.4

59.5

200

1171.5

464.7

56.7

760.6

321.6

62.6

72

240

1238.3

489.6

55.3

805.9

336.7

61.7

248

1249.7

493.8

55.1

813.6

339.3

61.6

200

794.7

777.5

52.9

569.7

569.7

60.7

62

240

815.5

798.2

51.8

583.0

583.0

59.9

248

819.0

801.7

51.6

585.1

585.1

59.7

200

929.2

715.3

54.3

583.4

563.2

60.8

80

67

240

973.1

732.5

53.1

601.8

592.6

60.0

248

980.7

735.5

52.9

605.0

593.8

59.9

200

1168.7

614.9

56.7

759.4

472.5

62.6

72

240

1235.3

639.5

55.3

803.2

487.1

61.7

248

1246.6

643.7

55.1

810.8

489.6

61.5

200

906.2

906.2

54.1

683.3

683.3

61.8

62

240

927.8

927.8

52.7

699.1

699.1

60.8

248

931.3

931.3

52.5

701.7

701.7

60.7

200

969.0

880.5

54.7

685.2

685.2

61.9

85

67

240

1006.1

895.3

53.4

701.2

701.2

60.8

248

1012.5

897.8

53.2

703.8

703.8

60.7

200

1170.1

766.1

56.7

783.6

631.4

62.8

72

240

1233.4

789.5

55.3

820.2

643.6

61.8

248

1244.3

793.5

55.0

826.5

645.7

61.7

Table PD-42. SCWF/SIWF 80 - Economizer Low Capacity - 29,800 cfm

Entering Water Temp

Entering Air

45 F

55 F

EDB

EWB

Flow

Total

Sensible

LWT

Total

Sensible

LWT

F

F

gpm

MBh

MBh

F

MBh

MBh

F

200

464.0

446.9

49.6

307.0

307.0

58.1

62

240

479.5

462.3

49.0

314.9

314.9

57.6

248

482.2

480.6

48.9

316.2

316.2

57.6

200

587.4

385.5

50.9

334.7

294.7

58.3

75

67

240

616.7

396.5

50.1

349.2

299.7

57.9

248

621.7

398.4

50.0

351.7

300.6

57.8

200

750.3

303.3

52.5

486.5

215.0

59.9

72

240

788.8

316.9

51.6

511.9

223.2

59.3

248

795.4

319.2

51.4

516.3

224.6

59.2

200

533.0

533.0

50.3

383.7

383.7

58.8

62

240

547.1

547.1

49.6

393.5

393.5

58.3

248

549.4

549.4

49.4

395.2

395.2

58.2

200

590.6

502.1

50.9

384.4

384.4

58.8

80

67

240

617.2

512.1

50.1

394.3

375.9

58.3

248

621.8

513.9

50.0

396.0

377.7

58.2

200

748.7

418.7

52.5

484.9

330.5

59.8

72

240

787.1

432.2

51.6

510.2

338.7

59.3

248

793.7

434.5

51.4

514.6

340.1

59.1

200

609.1

609.1

51.1

460.4

460.4

59.6

62

240

625.1

625.1

50.2

472.2

472.2

58.9

248

627.8

627.8

50.1

474.1

474.1

58.8

200

622.3

602.9

51.2

461.2

461.2

59.6

85

67

240

643.6

637.3

50.4

473.0

473.0

58.9

248

647.3

638.7

50.2

475.0

475.0

58.8

200

747.1

533.8

52.5

496.6

450.0

60.0

72

240

785.4

547.2

51.5

517.0

456.6

59.3

248

791.9

549.5

51.4

520.6

457.8

59.2
