Electrical Data
PKG-PRC002-EN 79
Selection Procedures
RLA = Rated Load Amps
Compressor LRA = Locked Rotor Amps
Fan Motor LRA = Locked Rotor Amps,
N.E.C. Table 430 - 150
FLA = Full Load Amps, N.E.C.
Table 430 - 150
Voltage utilization range is ±10 percent
Determination of minimum circuit
ampacity (MCA).
MCA = 1.25 x largest motor amps/VFD
amps (FLA or RLA) + the sum of the
remaining motor amps.
Determination of maximum fuse size
(MFS) and maximum circuit breaker size
(MCB)
MFS and MCB = 2.25 x largest motor
amps (FLA or RLA) + the sum of the
remaining motor amps.
Units with the dual power option require
separate MFS and MCB calculations for
each electrical circuit:
1) fans and 2) compressors.
If the rating value calulation does not
equal a standard over current protective
device rating, use the next lower standard
rating as the maximum.
Table ED-1. Number of Compressors per Unit
SCRF/SIRF 20 25 - 29 30 - 35 40 50 60
SCWF/SIWF 20 - 25 29 - 32 35 - 38 42 - 46 52 - 58 65 - 72 80
10 2 1 3 2 - 1 -
15 - 1 - 1 3 3 4
Table ED-2. SCWF/SIWF Compressor Electrical Data
200V 460V 575V
HP RLA LRA RLA LRA RLA LRA
10 33 269 14.5 117 11.5 94
15 46 409 20.5 178 16.5 143
Table ED-3. SCRF/SIRF Compressor Electrical Data
200V 460V 575V
HP RLA LRA RLA LRA RLA LRA
10 36.8 269 16.3 117 13.2 94
15 61.1 409 26 178 21.5 143
Table ED-4. Fan Without VFD Electrical Data
200V 460V 575V
HP FLA LRA FLA LRA FLA LRA
5 16.1 105 6.7 46 5.4 37
7.5 25.0 152 10.8 66 8.2 54
10 32.9 193 14.2 84 11.4 66
15 44.8 290 20.3 126 16.2 102
20 61.0 373 25.0 162 20.0 132
25 74.0 469 31.0 204 24.2 162
30 87.0 552 36.0 240 28.6 192
40 113.0 718 47.8 312 38.0 246
50 NA NA 62.0 390 49.2 312
Table ED-5. Fan with VFD Electrical Data
200V 460V
HP FLA LRA FLA LRA
7.5 29.0 152 14.3 66
10 38.3 193 18.1 84
15 42.7 290 25.8 126
20 55.2 373 32.4 162
25 67.8 469 38.9 204
30 82.0 552 39.0 240
40 108.6 718 51.0 312
50 NA NA 61.5 390
Note: Values are at the maximum VFD input rating and not the reduced motor values.
