Electrical Data

PKG-PRC002-EN

80

SCWF/SCRF

Table ED-6. Single Stage Electric Heat Electrical Data

SXWF

SXRF

Heat

200V

460V

Size

Size

Kw

Amps

Amps

20

-

18

50

21.7

22

-

18

50

21.7

25

20

18

50

21.7

29

25

23

63.8

27.7

32

29

23

63.8

27.7

35

30

27

75

32.5

38

35

27

75

32.5

42

-

31.5

87.4

37.9

46

40

31.5

87.4

37.9

52

-

39

108.3

46.9

58

50

39

108.3

46.9

65

-

48

133.2

57.7

72

-

48

133.2

57.7

80

60

48

133.2

57.7

Note:
Electric heat amperage should not be considered when determining minimum circuit ampacity. The current of the
unit in the heating mode will not exceed the current of the unit in the cooling mode.

Table ED-7. CCRC/CIRC Condenser Electrical Data

Unit Size

Rated

MFS.

Tons

Voltage

# Fans

FLA (ea.)

LRA (ea.)

MCA

MCB

20, 29

200

4

4.1

20.7

17.43

20

460

4

1.8

9

7.65

15

575

4

1.4

7.2

5.95

15

35, 40

200

6

4.1

20.7

25.63

30

460

6

1.8

9

11.25

15

575

6

1.4

7.2

8.75

15

50, 60

200

8

4.1

20.7

33.83

40

460

8

1.8

9

14.85

20

575

8

1.4

7.2

11.55

15

Note:
All motors for CCRC/CIRC units are rated at 1 hp (.7457 kW).
