General Data
PKG-PRC002-EN 17
SCWF/SIWF
20-38 Tons
Table GD-1. SCWF/SIWF Water-Cooled Self-Contained, 20-38 Tons
Unit Size 20 22 25 29 32 35 38
Compressor Data
Quantity 2 2 2 1/1 1/1 3 3
NominalTon/Comp 10 10 10 15/10 15/10 10 10
Circuits 2 2 2 2 2 3 3
Evaporator Coil Data
Rows 2 2 3 2 4 3 4
Sq. Ft. 21.81 21.81 21.81 29.98 29.98 31.35 31.35
Sq. m (2.03) (2.03) (2.03) (2.79) (2.79) (2.91) (2.91)
FPF 144 144 144 144 144 120 144
Condenser Data
Minimum GPM w/o Econ 36 36 36 46 46 54 54
Minimum liters / sec. w/o Econ (2.27) (2.27) (2.27) (2.9) (2.9) (3.41) (3.41)
Minimum GPM w/ Econ 41 41 41 60 60 65 65
Minimum liters / sec. w/ Econ (2.59) (2.59) (2.59) (3.79) (3.79) (4.1) (4.1)
Maximum GPM 80 80 80 102 102 119 119
Maximum liters / sec. (5.05) (5.05) (5.05) (6.44) (6.44) (7.51) (7.51)
Evaporator Fan Data
Quantity 1 1 1 1 1 1 1
Size (Dia. - inches) 16.5" 16.5" 16.5" 18.25" 18.25" 20" 20"
Size (Dia. - mm) (419.1) (419.1) (419.1) (463.6) (463.6) (508) (508)
Minimum HP 5 5 5 5 5 5 5
Minimum kW (3.73) (3.73) (3.73) (3.73) (3.73) (3.73) (3.73)
Maximum HP 20 20 20 25 25 25 25
Maximum kW (14.91) (14.91) (14.91) (18.64) (18.64) (18.64) (18.64)
Minimum Design CFM 6325 6325 6500 8700 8700 9100 9880
Minimum Design liter / sec. (2985) (2985) (3068) (4106) (4106) (4295) (4663)
Maximum Design CFM 8500 9350 10625 12325 13600 14875 16150
Maximum Design liter / sec. (4012) (4413) (5014) (5817) (6418) (7020) (7622)
General Data
EER 12.9 12.6 13.4 14.1 13.6 13.3 13.4
IPLV 13.6 12.9 13.6 14.5 13.0 12.8 12.4
Refrigerant Charge - lbs. R-22
Circuit A 24 24 24 28 30 24 25
Circuit B 24 24 24 24 25 24 25
Circuit C - - - - - 24 25
Refrigerant Charge - kg R-22
Circuit A
(10.9) (10.9) (10.9) (12.7) (13.6) (10.9) (11.3)
Circuit B (10.9) (10.9) (10.9) (10.9) (11.3) (10.9) (11.3)
Circuit C - - - - - (10.9) (11.3)
Capacity Steps - % 100/53/0 100/53/0 100/53/0 100/62/39/0 100/59/39/0 100/65/31/0 100/65/30/0
Filter Data
Quantity 8 8 8 8 8 8 8
Size (inches) 20x18x2 20x18x2 20x18x2 20x18x2 20x18x2 20x18x2 20x18x2
Size (mm) (508 X 457 X 51) (508 X 457 X 51) (508 X 457 X 51) (508 X 457 X 51) (508 X 457 X 51) (508 X 457 X 51) (508 X 457 X 51)
Quantity 4 4 4 4 4 4 4
Size (inches) 20x20x2 20x20x2 20x20x2 20x20x2 20x20x2 20x20x2 20x20x2
Size (mm) (508 X 508 X 51) (508 X 508 X 51) (508 X 508 X 51) (508 X 508 X 51) (508 X 508 X 51) (508 X 508 X 51) (508 X 508 X 51)
Notes:
1. Compressors are Trane 3D
® scroll.
2. EER and IPV are rated in accordance to the ARI Standard 340/360-93. Based on 80/67 F (26.7/19.4 C) to the evaporator coil,
nominal airflow and 85-95 F (29.4/35 C) condenser water.
3. All units operate with R-22. Units ships with full operating charge.
4. Maximum cfm limits are set to prevent moisture carryover on the evaporator coil.
5. Minimum cfm limits are set to ensure stable thermal expansion valve operation at low load conditions.
6. Filter sizes are for units without hot water or steam heating coils.
Table GD-2. SCWF/SIWF Refrigerant Circuits,
Number of Compressors by Circuit
Circuit 1 2 3 4
Unit Size
20/22/25 Ton
1- 10T 1- 10T
29/32 Ton 1- 15T 1- 10T
35/38 Ton 1- 10T 1- 10T 1- 10T
42/46 Ton 1- 15T 1- 10T 1- 10T
52/58 Ton 1- 15T 1- 15T 1- 15T
60/72 Ton 1- 15T 1- 15T 1- 15T 1- 10T
80 Ton 1- 15T 1- 15T 1- 15T 1- 15T
Note: This table depicts compressor location in unit, plan
view from left corner.
