General Data
PKG-PRC002-EN 21
Table GD-7. Self-Contained Heating Coil
Unit Size SCWF 20 - 38 SCWF 42 - 80 SCRF 20 - 35 SCRF 40 - 60
Steam Coil
Coil Type NS NS NS NS
Rows Rows 1 1 1 1
No./Size (inches) ((2) 24x58) ((2) 30x81) ((2) 24x58) ((2) 30x81)
No./Size (mm) ((2) 609.6x1473.2) ((2) 762x2057.4) ((2) 609.6x1473.2) ((2) 762x2057.4)
FPF 42 42 42 42
Hot Water Coil
Coil Type
WC WC WC WC
Rows 1 1 1 1
No./Size (inches) (2) 24x58 (2) 30x81 (2) 24x58 (2) 30x81
No./Size (mm) ((2) 609.6x1473.2) ((2) 762x2057.4) ((2) 609.6x1473.2) ((2) 762x2057.4)
FPF 80 80 80 80
Filter Data
Quantity 4 4 4 4
Size (inches) 20x18x2 16x20x2 20x18x2 16x20x2
Size (mm) (508x457x51) (406x508x51) (508x457x51) (406x508x51)
Quantity 8 8 8 8
Size (inches) 20x20x2 16x25x2 20x20x2 16x25x2
Size (mm) (508x508x51) (406x635x51) (508x508x51) (406x635x51)
Quantity 2 2
Size (inches) 20x20x2 20x20x2
Size (mm) (508x508x51) (508x508x51)
Quantity 4 4
Size (inches) 20x25x2 20x25x2
Size (mm) (508x635x51) (508x635x51)
Notes:
1. Hot water and steam heating coils have Prima-Flo
® fins without turbulators.
2. For coil capacites, use TOPSS ™ (Trane Official Product Selection Program).
3. Full capacity coils consist of two coils stacked and piped in parallel.
Heating Coil
