Table PD-14. SCWF/SIWF 32 - Economizer Full Capacity - 12,800 cfm
Entering Water Temp
Entering Air
45 F
55 F
EDB
EWB
Flow
Total
Sensible
LWT
Total
Sensible
LWT
F
F
gpm
MBh
MBh
F
MBh
MBh
F
80
325.8
296.8
53.1
206.2
206.2
60.2
62
96
340.9
303.2
52.1
212.0
212.0
59.4
102
345.5
305.1
51.8
213.7
213.7
59.2
80
410.8
250.1
55.3
239.5
186.4
61.0
75
67
96
438.2
260.9
54.1
252.7
191.1
60.3
102
446.8
264.3
53.8
257.1
192.7
60.0
80
524.5
207.6
58.1
341.3
144.0
63.5
72
96
561.3
221.1
56.7
366.1
152.2
62.6
102
572.8
225.3
56.2
374.0
154.9
62.3
80
359.2
351.8
54.0
257.7
257.7
61.4
62
96
371.0
363.6
52.7
264.8
264.8
60.5
102
374.6
367.2
52.3
266.9
266.9
60.2
80
419.5
320.1
55.5
265.0
262.1
61.6
80
67
96
443.6
329.6
54.2
275.3
265.8
60.7
102
451.2
332.6
53.8
278.6
267.0
60.5
80
523.3
274.5
58.1
342.0
211.3
63.6
72
96
560.0
288.2
56.7
365.5
219.1
62.6
102
571.4
292.5
56.2
373.1
221.7
62.3
80
409.2
409.2
55.2
309.1
309.1
62.7
62
96
420.9
420.9
53.8
317.6
317.6
61.6
102
424.4
424.4
53.3
320.1
320.1
61.3
85
80
439.0
394.1
56.0
310.1
310.1
62.8
67
96
459.6
402.3
54.6
318.6
318.6
61.6
102
466.1
404.9
54.1
321.2
321.2
61.3
80
526.4
342.5
58.2
355.4
282.6
63.9
72
96
560.6
355.2
56.7
375.4
289.3
62.8
102
571.4
359.3
56.2
381.8
291.5
62.5
32 Ton
Table PD-15. SCWF/SIWF 32 - Economizer Low Capacity - 12,800 cfm
Entering Water Temp
Entering Air
45 F
55 F
EDB
EWB
Flow
Total
Sensible
LWT
Total
Sensible
LWT
F
F
gpm
MBh
MBh
F
MBh
MBh
F
80
214.8
207.4
50.4
142.6
142.6
58.6
62
96
224.4
222.7
49.7
147.3
147.3
58.1
102
227.4
223.9
49.5
148.7
148.7
57.9
80
268.8
177.2
51.7
155.5
136.5
58.9
75
67
96
286.5
183.8
51.0
163.6
139.3
58.4
102
292.0
185.9
50.7
166.4
140.3
58.3
80
343.2
138.9
53.6
223.5
99.0
60.6
72
96
366.3
147.1
52.6
238.5
103.8
60.0
102
373.5
149.6
52.3
243.3
105.3
59.8
80
246.7
246.7
51.2
178.3
178.3
59.5
62
96
255.3
255.3
50.3
184.1
184.1
58.8
102
257.8
257.8
50.1
185.9
185.9
58.6
80
272.1
231.7
51.8
178.6
178.6
59.5
80
67
96
287.9
237.7
51.0
184.7
176.7
58.8
102
292.9
239.6
50.7
186.7
178.6
58.7
80
342.5
192.3
53.6
222.8
152.4
60.6
72
96
365.5
200.4
52.6
237.7
157.2
60.0
102
372.7
202.9
52.3
242.5
158.7
59.8
80
282.0
282.0
52.0
214.0
214.0
60.3
62
96
291.8
291.8
51.1
220.9
220.9
59.6
102
294.7
294.7
50.8
223.0
223.0
59.4
80
288.3
279.8
52.2
214.4
214.4
60.4
85
67
96
301.4
296.0
51.3
221.3
221.3
59.6
102
305.5
297.6
51.0
223.5
223.5
59.4
80
342.0
245.6
53.5
230.4
208.3
60.8
72
96
364.8
253.6
52.6
242.5
212.2
60.1
102
371.9
256.1
52.3
246.5
213.5
59.8
