Dimensions
and Weights
PKG-PRC002-EN 86
Hot Water Coil Piping Locations - English (inches)
A B C D E F G H
Unit Sizes 20 - 38 60 3 /
8
82 7 /
8
18 20 5 /
8
8 1 /
8
22 3 /
8
3 5 /
8
8 1 /
4
Unit Sizes 42 - 80 72 7 /
8
105 1 /
4
18 24 1 /
2
10 3 /
4
13 1 /
4
3 5 /
8
8 1 /
4
Hot Water Coil Piping Locations - Metric (mm)
A B C D E F G H
Unit Sizes 20 - 38 1534 2105 457 524 206 568 92 210
Unit Sizes 42 - 80 1851 2680 457 404.9 273 337 92 210
Piping Locations For Steam Coils - English (inches)
A B C D E F G H J K L M N
Unit Sizes 20 - 38 60 3 /
8
82 7 /
8
18 - - 22 3 /
8
- 3 18 1 /
2
3 7 /
8
5 4 3 /
8
1 1 /
4
Unit Sizes 42 - 80 72 7 /
8
105 1 /
4
18 - - 13 1 /
4
- 3 22 1 /
8
6 3 /
8
5 3 /
8
4 3 /
8
1 1 /
4
Piping Locations For Steam Coils - Metric (mm)
A B C D E F G H J K L M N
Unit Sizes 20 - 38 1534 2105 457 - - 568 - 76 470 98 127 111 32
Unit Sizes 42 - 80 1851 2680 457 - - 337 - 76 562 162 137 111 32
Notes:
1. All coils are factory
mounted, piped, and
wired.
2. All piping connections
are 1- 1 /
2
” (38.1mm)
female NPT fittings.
Hot Water Coil
Notes:
1. All coils are factory
mounted, piped, and
wired.
2. All piping connections
are 1- 1 /
2
” (38.1mm)
female NPT fittings.
Steam Coil
Self-Contained
Heating Coils
Main Control Panel
Main Control Panel
Air Inlet
Hot Water Outlet Connection
Hot Water Inlet Connection
H
F
G
A
B
E
D
C
Air Inlet
C
A
M
F
H
J
K
L
B
Condensate Return
Steam Inlet Connection
Vacuum Trap Connection
Condensate Return
Vacuum Trap Connection
N
