General Data
PKG-PRC002-EN
20
CCRC/CIRC
Table GD-6. CCRC/CIRC Remote Air-Cooled Condenser
Unit Size
20
29
35
40
50
60
Gross Heat Rejection (MBH)
493
538
640
725
1040
1122
Gross Heat Rejection (kW)
(144.5)
(157.7)
(187.6)
(212.5)
(304.8)
(328.8)
Condenser Fan Data
Number/Type
4/Prop
4/Prop
6/Prop
6/Prop
8/Prop
8/Prop
Size (inches)
26
26
26
26
26
26
Size (mm)
(660.4)
(660.4)
(660.4)
(660.4)
(660.4)
(660.4)
Fan Drive
Direct
Direct
Direct
Direct
Direct
Direct
No. of Motors/HP ea.
4/1
4/1
6/1
6/1
8/1
8/1
Nominal CFM
18,800
21,200
35,600
39,800
46,200
56,400
Nominal (liters / sec)
(8873)
(10005)
(16801)
(18784)
(21804)
(26618)
Condenser Coil Data
Circuit 1 Size (in.)
1/46x71
1/64x71
2/46x71
2/46x71
2/64x71
2/64x71
Circuit 1 Size (mm)
(1/1168x1803)
(1/1626x1803)
(2/1168x1803)
(2/1168x1803)
(2/1626x1803)
(2/1626x1803)
Circuit 2 No./Size (in.)
1/46x71
1/46x71
1/46x71
1/64x71
1/64x71
2/64x71
Circuit 2 No./Size (mm)
(1/1168x1803)
(1/1168x1803)
(1/1168x1803)
(1/1626x1803)
(1/1626x1803)
(2/1626x1803)
Face Area (sq. ft.)
45.4
54.2
68
76.9
94.7
126.2
Face Area (sq.m)
(4.2)
(5)
(6.3)
(7.1)
(8.8)
(11.7)
Rows/fpf
4/144
4/144
4/144
4/144
4/144
4/144
Ambient Temperature Operating Range
Standard Ambient (F)
50-115
50-115
50-115
50-115
50-115
50-115
Standard Ambient (C)
(10 - 46.1)
(10 - 46.1)
(10 - 46.1)
(10 - 46.1)
(10 - 46.1)
(10 - 46.1)
Low Ambient Option (F)
0-115
0-115
0-115
0-115
0-115
0-115
Low Ambient Option (C)
(-17.8 - 46.1)
(-17.8 - 46.1)
(-17.8 - 46.1)
(-17.8 - 46.1)
(-17.8 - 46.1)
(-17.8 - 46.1)
Notes:
1. Gross Heat Rejection is at a 20 F (-6.7 C) ITD (Initial Temperature Difference) between condensing temperature and ambient air entering condenser (includes the effect of
subcooling).
2. Operating charge is for entire unit, including 100 feet of interconnecting piping.
3. At conditions of 95 F (35 C), condenser is 95 percent full.
Table GD-7. SCRF/SIRF Air–Cooled Self–Contained and CCRC/CIRC Remote Air-Cooled Condenser
Unit Size
20
29
35
40
50
60
Refrigerant Circuit General Data
No. of Refrigerant Circuits
2
2
2
2
2
2
Operating Charge - lbs. R-22
36/36
58/36
72/36
94/36
115/58
115/115
Operating Charge - kg R-22
(16.3/16.3)
(26.3/16.3)
(32.7/16.3)
(42.6/16.3)
(52.2/26.3)
(52.2/56.7)
Cond. Storage Cap. - lbs. R-22
44/44
61/44
88/44
105/44
122/122
122/122
Cond. Storage Cap. - kg R-22
(20/20)
(27.7/20)
(39.9/20)
(47.6/20)
(55.3/55.3)
(55.3/55.3)
Notes:
1. Gross heat rejection is at a 20 F (-6.7 C) ITD (initial temperature difference) between condensing temperature and ambient air entering condenser (includes the effect of
subcooling).
2. Operating charge is for entire system, which includes the air–cooled self–contained, remote air–cooled condenser, and 25 feet of interconnecting refrigerant piping.
3. At conditions of 95 F (35 C), condenser storage capacity is 95% full.
4. To determine the correct amount of refrigerant needed for a particuliar application, reference the
Trane Reciprocating Refrigeration Manual.
