Ricoh H545 User Manual
Page 24

Machine Layout
8
2
5.
Main switch
The main switch turns your machine on
and off.
6.
Operation panel
Key panel for operating the machine.
7.
Optional Handset
8.
Document guide
Match the document guide to the size of
your original documents.
9.
Document table
Document table holds up to 30 sheets
which are fed one at a time. Place your
original documents here.
10.
Multi-purpose Feeder
Multi-purpose Feeder can be loaded with
various kind of printable media.
11.
Cover release button
Pull this catch to release the top cover.
