2. Machine Layout
Part Names
1.
Lower paper cassette
The optional lower paper cassette holds
more paper.
2.
Main paper cassette
The main paper cassette holds copy pa-
per.
3.
Print delivery tray
Copies, incoming faxes, and prints gener-
ated using the Optional PC Interface kit
are delivered here.
4.
Document delivery tray
Scanned documents are stacked on the
Document delivery Tray.
TSTH060N
