Replacing The Toner Cassette And Cleaning Pad

87

5

B

Grasp the old toner cassette as shown, and lift it out carefully.

R

WARNING:

Do not incinerate waste toner. Toner dust may ignite suddenly when exposed
to an open flame.

C

Remove the old cleaning pad.

D

Install the cleaning pad a shown in the illustration.
