Clearing a document jam, 6clearing a document jam – Ricoh H545 User Manual
Page 123
Clearing a Document Jam
107
6
Clearing a Document Jam
When an original is jammed, CLEAR ORIGINAL is displayed — follow this pro-
cedure to solve the problem.
Note
❒ If copies, fax message or prints are jammed, follow the next procedure.
A
Open the top cover to an angle of about 45
°°°°
.
B
Remove the original.
C
Close the top cover.
TSTJ030N
TSTJ040N
