ST7000 Plus Autopilot Control Unit Owner’s Handbook
Position information not received
• Navigator not transmitting the correct position data.
The autopilot will not auto advance to the next waypoint
• No bearing to waypoint information received from the navigator.
A series of rotating dashes are displayed on screen
• Compass deviation correction or dockside rudder calibration is
running.
The display shows a series of stationary dashes
• Data is not being received – check the cabling.
The display shows NO DATA
• The signals received from the navigator are too weak – refer to the
navigator handbook for further action.
