Raymarine Raystar 125 User Manual

Raystar 125 gps receiver owner's handbook, What tools do i need to install it

background image

1

Drill

6mm (

1

/

4

in)

Drill bit

20mm (

13

/

16

in)

Drill bit

Phillips
screwdriver

Adhesive tape

What tools do I need to install it?....

Part No: R38103

Raystar RS125 GPS Receiver

Part No: E35018

Pole mount kit

Studs (x2)

Thumb nuts (x2)

Part No: R38104

10m (33ft) NMEA/SeaTalk

connection cable

Flush mount gasket

Screws (x2)

The Raystar RS125 GPS Receiver has no user serviceable parts.

D7471_2

3- way

Scotchlok

connectors (x5)

TM

Your handbook contains an explanation of how to install,
operate and maintain your Raystar RS125 GPS Receiver.

Intended Use
This product is a GPS antenna with a built-in position
fixing receiver using either NMEA0183 (Version 2.3 or
later), or Raymarine SeaTalk data output. The intended
application is for leisure marine boats and workboats not
covered by IMO/SOLAS carriage requirements.

Raystar 125 GPS Receiver
Owner's Handbook

www.raymarine.com

Welcome to the Raystar RS125 GPS Receiver

What's in the box?....
