Chapter 6: Post Installation Procedures 69
• A cabling error. Check for an open circuit, short circuit or reversed
wires.
• The navigator is not configured to transmit the required data format.
• The signals being received by the navigator are too weak for
reliable navigation. Refer to the navigator handbook for further
action.
Wind Transducer Interface
If the ST7000 Plus is connected to a wind instrument via its NMEA
data port or SeaTalk, then the link between the two instruments should
be checked by pressing
standby and auto together.
The ST7000 Plus should display the Wind mode screen, with the
locked wind angle and locked heading as shown.
SeaTalk Interface
If the ST7000 Plus has been linked to other SeaTalk instruments via
SeaTalk, the link can be checked as follows:
1. Press standby.
2. Select display illumination level 3 on any other SeaTalk
instrument or autopilot control unit.
