Page 79
62
ST7000 Plus Autopilot Control Unit Owner’s Handbook
Red
(Data In +ve)
Blue
(Data In -ve)
D3442-1
Navigator
with NMEA output
NMEA Cable Connectors
• NMEA connections are made using spade connectors.
• When fitting the spade connectors, make sure the connector fits
securely over the blade and not between the connector and its
plastic insulating boot. Incorrectly fitted connectors will give
intermittent contact and result in faulty control unit operation.
NMEA Data
The following NMEA 0183 wind and navigation data can be decoded
by the ST7000 Plus.
118ch05.p65
07/01/99, 12:43
62
