Chapter 5: Installation 63
Data NMEA 0183
Latitude and Longitude GLL, RMC, RMA, GLP, GOP, GXP, GGA,
GDP
Course Over Ground VTG, RMC, RMA
Speed Over Ground VTG, RMC, RMA
Cross Track Error APB, APA, RMB, XTE
Bearing to Waypoint APB, BWR, BWC, RMB
Distance to Waypoint BWR, BWC, RMB
Waypoint Number APB, APA, BWR, BWC, RMB
Apparent Wind Speed VWR, MWV
Apparent Wind Angle VWR, MWV
Speed Through Water VHW
Depth DBT
Water Temperature MTW
Transmission of NMEA Data on SeaTalk
If any of the above NMEA data is received and the equivalent data is
not present on SeaTalk, the ST7000 Plus will transmit the data onto
SeaTalk to make it available to other SeaTalk compatible instruments.
Depth is transmitted in the units defined by the first depth page in the
data page rollover. Water temperature is always transmitted in ºC.
If you wish to transmit NMEA information to other equipment a
SeaTalk-to-NMEA bridge should be installed.
5.4 Functional Test (Repeater Unit)
If you have installed your ST7000 Plus as a repeater unit on an
autopilot system, you should perform the functional test described in
this section. However, if you have installed the ST7000 Plus as the
only control unit for a Type 100/300 course computer, you should now
carry out the procedures in Chapter 6, Post Installation Procedures.
