40 ST7000 Plus Autopilot Control Unit Owner’s Handbook
Data Displayed as
Water Temperature, Degrees C WATER ºC
Water Temperature, Degrees F WATER ºF
Course Over Ground COG
Speed Over Ground SOG (followed by units)
Cross Track Error XTE (followed by units)
Distance to Waypoint DTW (followed by units)
Bearing to Waypoint BTW
Watch WATCH
Universal Time Constant UTC
ST60/ST80 Instrument Remote Control INST REM
Maxiview Remote Control MAXI REM
The units displayed for all data other than depth and water temperature
depend on the currently selected SeaTalk display units.
The default pages are:
Data Page Default Setting
1 XTE (Cross Track Error)
2 BTW (Bearing to Waypoint)
3 DTW (Distance to Waypoint)
4 to 15 NOT USED
For each setup page, scroll forwards or backwards using the +1 or -1
keys, until the required page title is displayed.
Press disp disp disp disp disp to move on to the next Data Page selection screen, and
repeat the selection procedure.
Notes:
1.
If you set a page to NOT USED, it is omitted from the display cycle
during normal operation. For example, with the default page
settings only three pages are displayed in the sequence.
