60 ST7000 Plus Autopilot Control Unit Owner’s Handbook
4. Screw the fixing studs (2) into the display head.
5. Pass the cables (SeaTalk, NMEA) through the bulkhead.
6. Fit the cables to the appropriate terminals (see relevant subsection
for connection details of each item).
7. Fit the display head to the bulkhead.
8. Assemble the thumb nuts (3) onto the fixing studs (2).
9. Tighten the thumb nuts by hand until the display head is secure.
Under no circumstances must a wrench be used to tighten the
thumb nuts.
Power
Power to the ST7000 Plus should be supplied by the associated
autopilot, in accordance with the instructions in the relevant autopilot
handbook.
Connections to the SeaTalk Bus
SeaTalk Cables
The ST7000 Plus is supplied with a 9 m SeaTalk cable as standard.
The following table lists other cables available from your dealer:
Part No: Type Length
D187 Flat to a male round connector 0.15 m
D188 Flat to a female round connector 0.3 m
D284 Flat moulded plugs at both ends 1 m
D285 Flat moulded plugs at both ends 3 m
D286 Flat moulded plugs at both ends 6 m
D287 Flat moulded plugs at both ends 9 m
Cable Types
The following illustration shows the different types of SeaTalk cables
available.
