EFFECT 1 Send (Effect 1 send level)
Specify the volume level (0Ð127) of the signal that is sent to
the EFFECT 1 buss. The default setting is 100.
EFFECT 1 Pan (Effect 1 pan)
EFFECT 1 Bal (Effect 1 balance)
For channels on which Channel Link is ÒOff,Ó this sets the
panning (L63Ð0ÐR63) of the stereo signal which is output to
the EFFECT 1 buss. ТL63У is far left, and ТR63У is far right.
For channels on which Channel Link is ТOn,У this sets the
left/right volume balance (L63Ð0ÐR63) of the stereo signal
from the paired channels which is output to the EFFECT 1
buss.
The default value is Т0У (center).
EFFECT 2 (Effect 2 switch)
Specify how the signal is sent to the EFFECT 2 buss.
Off: The signal will not be sent.
PreFade: The signal will be taken before the channel
fader.
PstFade: The signal will be taken after the channel
fader.
Insert: The effect will be inserted between the equal-
izer and fader of the channel.
InsertL: Insert into the L side of a stereo effect.
InsertR: Insert into the R side of a stereo effect.
InsertS: Insert the L side and R side of a stereo effect
in series.
* If the effect is inserted in another channel, the value will
appear as ТСР,У and cannot be selected.
EFFECT 2 Send (Effect 2 send level)
Specify the volume level (0Ð127) of the signal that is sent to
the EFFECT 2 buss. The default setting is 100.
EFFECT 2 Pan (Effect 2 pan)
EFFECT 2 Bal (Effect 2 balance)
For channels on which Channel Link is ÒOff,Ó this sets the
panning (L63Ð0ÐR63) of the stereo signal which is output to
the EFFECT 2 buss. ТL63У is far left, and ТR63У is far right.
For channels on which Channel Link is ТOn,У this sets the
left/right volume balance (L63Ð0ÐR63) of the stereo signal
from the paired channels which is output to the EFFECT 2
buss.
The default value is Т0У (center).
Master block settings
EFF1 INS Sw (Effect 1 insert switch)
Off: The effect will not be inserted into the master out
(same as Ver.1).
On: The effect will be inserted into the master out.
EFF1 SND Lev (Effect 1 send level)
Adjust the send level. The default value is 100.
EFF1 SND Bal (Effect 1 send balance)
Adjust the left/right volume balance. The initial value is 0
(center).
EFF1 RTN to (Effect 1 return to)
Select the output destination of effect 1. The busses that can
be selected will depend on the current mixer mode.
When in INPUT ➝ TRACK mode
MIX: the MIX buss (stereo)
AUX: the AUX buss (stereo)
When in INPUT MIX mode / TRACK MIX mode
MIX:
the MIX buss (stereo)
1-2: REC buss 1-2
3-4: REC buss 3-4
5-6: REC buss 5-6
7-8: REC buss 7-8
EFF1 RTN Lev (Effect 1 return level)
Set the output level (0Ð127) of effect 1.
EFF1 Bal (Effect 1 balance)
Set the left/right volume balance (L63Ð0ÐR63) of effect 1.
EFF2 INS Sw (Effect 2 insert switch)
Off: The effect will not be inserted into the master out
(same as Ver.1).
On: The effect will be inserted into the master out.
EFF2 SND Lev (Effect 2 send level)
Adjust the send level. The default value is 100.
EFF2 SND Bal (Effect 2 send balance)
Adjust the left/right volume balance. The initial value is 0
(center).
EFF2 RTN to (Effect 2 return to)
Select the output destination of effect 2. The busses that can
be selected will depend on the current mixer mode.
When in INPUT ➝ TRACK mode
MIX: the MIX buss (stereo)
AUX: the AUX buss (stereo)
When in INPUT MIX mode / TRACK MIX mode
MIX: the MIX buss (stereo)
1-2: REC buss 1-2
3-4: REC buss 3-4
5-6: REC buss 5-6
7-8: REC buss 7-8
EFF2 RTN Lev (Effect 2 return level)
Set the output level (0Ð127) of effect 2.
EFF2 Bal (Effect 2 balance)
Set the left/right volume balance (L63Ð0ÐR63) of effect 2.
