Roland Vs-880 - Manual (Page 139)

Parameter name Display Value Initial value
AUX Switch AUX Sw Off, PreFade, PstFade Off
AUX Level AUX Level 0Ð127 100
AUX Pan/Balance AUX Pan/AUX Bal L63Ð0ÐR63 0
Channel Link Channel Link Off, On Off
Effect 1 Switch EFFECT1 Off, Prefade, PstFade, Insert, Off
InsertL, InsertR, InsertS
Effect 1 Send Level EFFECT1 Send 0Ð127 100 (*2)
Effect 1 Pan/Balance EFFECT1 Pan/EFFECT1 Bal L63Ð0ÐR63 0 (*2)
Effect 1 Insert Level EFFECT1 InsSend 0–127 100 (*3)
Effect 1 Insert Return Level EFFECT1 InsRtn 0–127 100 (*3)
Effect 2 Switch EFFECT2 Off, Prefade, PstFade, Insert, Off
InsertL, InsertR, InsertS
Effect 2 Send Level EFFECT2 Send 0Ð127 100 (*2)
Effect 2 Pan/Balance EFFECT2 Pan/EFFECT1 Bal L63Ð0ÐR63 0 (*2)
Effect 2 Insert Level EFFECT2 InsSend 0–127 100 (*3)
Effect 2 Insert Return Level EFFECT2 InsRtn 0–127 100 (*3)
* 1 Valid only for 8 channels of INPUT MIX/TRACK MIX (When the master block Equalizer Select is Ò3 Band EQÓ).
* 2 Valid when Effect Switch is ÒPrefade, PstFade.Ó
* 3 Valid when Effect Switch is ÒInsert, InsertL, InsertR, InsertS.Ó
TRACK MIX Mode
Parameter name Display Value Initial value
BUSS Switch BUSS Sw Off, PreFade, PstFade PstFade
BUSS Select BUSS Sel MIX, 1-2, 3-4, 5-6, 7-8 MIX
BUSS Level BUSS Level 0Ð127 100
BUSS Pan/Balance BUSS Pan/BUSS Bal L63Ð0ÐR63 0
V-Track V.Track 1Ð8 1
Equalizer Switch EQ Switch Off, On On
Equalizer Low Gain EQL -12Ð12 dB 0 dB
Equalizer Low Frequency EQL 40 Hz Ð 1.5 kHz 300 Hz
Equalizer Mid Gain EQM -12–12 dB 0 dB (*1)
Equalizer Mid Q EQM Q 0.5–16 0.5 (*1)
Equalizer Mid Frequency EQM F 200 Hz–8 kHz 1.4 kHz (*1)
Equalizer High Gain EQH -12Ð12 dB 0 dB
Equalizer High Frequency EQH 500 Hz Ð 18 kHz 4 kHz
AUX Switch AUX Sw Off, PreFade, PstFade Off
AUX Level AUX Level 0Ð127 100
AUX Pan/Balance AUX Pan/AUX Bal L63Ð0ÐR63 0
Channel Link Channel Link Off, On Off
Effect 1 Switch EFFECT1 Off, Prefade, PstFade, Insert, Off
InsertL, InsertR, InsertS
Effect 1 Send Level EFFECT1 Send 0Ð127 100 (*2)
Effect 1 Pan/Balance EFFECT1 Pan/EFFECT1 Bal L63Ð0ÐR63 0 (*2)
Effect 1 Insert Level EFFECT1 InsSend 0–127 100 (*3)
Effect 1 Insert Return Level EFFECT1 InsRtn 0–127 100 (*3)
Effect 2 Switch EFFECT2 Off, Prefade, PstFade, Insert, Off
InsertL, InsertR, InsertS
Effect 2 Send Level EFFECT2 Send 0Ð127 100 (*2)
Effect 2 Pan/Balance EFFECT2 Pan/EFFECT1 Bal L63Ð0ÐR63 0 (*2)
Effect 2 Insert Level EFFECT2 InsSend 0–127 100 (*3)
Effect 2 Insert Return Level EFFECT2 InsRtn 0–127 100 (*3)
Equalizer/Effect Pre-Insert Switch EQ/Eff PreIns Off, On Off
Track Level TrackLevel -12–12 dB 0 dB
* 1 Valid only for 8 channels of INPUT MIX/TRACK MIX.
* 2 Valid when Effect Switch is ÒPrefade, PstFade.Ó
* 3 Valid when Effect Switch is ÒInsert, InsertL, InsertR, InsertS.Ó
Parameter list
139
Appendices
