1.
Make sure that the mixer mode is INPUT
➝
TRACK.
2.
Connect an instrument such as a keyboard to the INPUT1 jack, and a mic to the INPUT2 jack.
3.
Press channel 1 [CH EDIT].
4.
Hold down [SHIFT] and press channel 7 [EFFECT-1(CH EDIT)].
The display will indicate ÒEFFECT1=Ó.
5.
Insert the effect. Rotate the TIME/VALUE dial. For this example, select “InsertL” so that the
sound of the instrument will be inserted into the left channel.
EFFECT1 (Effect 1 switch)
Select how the signal will be sent to the EFFECT1 buss.
Off:
The signal will not be sent.
PreFade:
The signal from before the channel fader will be sent.
PstFade:
The signal that passed through the channel fader will be sent.
Insert:
Insert between the equalizer and fader.
InsertL:
Insert into the L side of a stereo effect.
InsertR:
Insert into the R side of a stereo effect.
InsertS:
Insert the L side and R side of a stereo effect in series.
* If the effect is inserted in another channel, the value will appear as ТСР,У and cannot be selected.
6.
Press PARAMETER [
].
The display will indicate ÒEFF1 InsSend=Ó.
7.
Adjust the send level to effect 1 (Vocoder). Rotate the TIME/VALUE dial.
EFF1 InsSend (Effect 1 insert send level)
Specify the volume level (0Ð127) of the signal that will be inserted into the effect. The default value
is 100.
8.
Press PARAMETER [
].
The display will indicate ÒEFF1 InsRtn=Ó.
9.
Adjust the return level from effect 1 (Vocoder). Rotate the TIME/VALUE dial.
EFF1 InsRtn (Effect 1 insert return level)
Specify the volume level (0Ð127) of the signal that is output from the effect. The default value is
100.
10.
Press PARAMETER [
] twice.
The display will indicate ÒEQ/EffPreInsÓ.
11.
Rotate the TIME/VALUE dial. For this example, select “On” so that the sound that has passed
through the effect will be recorded.
EQ/EffPreIns (Equalizer/effect pre-insert switch)
Select whether the equalizer and effect will be inserted during recording.
Off:
They will not be inserted (same as Ver.1).
On:
The signal into which the equalizer and effect have been inserted will be recorded.
12.
Press channel 2 [CH EDIT].
13.
As in steps 4–11, make settings as when inserting an effect. However in step 5, select
“InsertR” so that the mic sound will be inserted into the right channel.
14.
Press [EFFECT] several times until “EFF EFFECT-1 PRM ?” appears.
15.
Press [YES].
16.
Select effect 1. Rotate the TIME/VALUE dial. For this example, select an effect such as A84
Vocoder.
17.
Press [YES].
18.
Set the track status of tracks 1 and 2 to REC.
When you begin recording, the vocoded sound will be recorded.
