Roland Vs-880 - Manual (Page 26)

RMF (Realtime modify filter)
RMF Off, On
Type LPF, BPF, HPF
CutOff 0Ð100
Reso 0Ð100
Gain 0Ð24 dB
RMF (Realtime modify filter)
Turn the realtime modify filter on/off. If this is turned off,
the following items will not be displayed.
Type (Filter type)
Select the filter type.
LPF: Low pass filter
BPF: Band pass filter
HPF: High pass filter
CutOff
Adjust the cutoff frequency.
Reso (Resonance)
Adjust the resonance.
Gain
Adjust the volume level of the sound that has passed
through the realtime modify filter.
NS (Noise suppressor)
Thresh 0Ð100
Release 0Ð100
Thresh (Threshold)
Adjust the level at which the noise suppressor will begin to
take effect.
Release
Adjust the time from when the noise suppressor begins to
take effect until the volume reaches 0.
● 4-Band Parametric Equalizer
This is a 4-band parametric equalizer. It can be used either
as two monaural units or as one stereo unit.
LNK (Link)
EQLink Off, On
EQLink (Equalizer link switch)
This is a link switch for channels A and B. If this is turned
off, the channels will function independently as two
monaural channels.
If this is turned on, both channels will be controlled simul-
taneously by the settings of channel A.
EQA/EQB (Parametric equalizer channel A / channel B)
EQAch(EQBch) Off, On
InputG -60Ð12dB
LowType Shlv, Peak
LowG -12Ð12 dB
LowF 20Ð2000 Hz
LowQ 0.3Ð10
LoMidG -12Ð12 dB
LoMidF 200Ð8000 Hz
LoMidQ 0.3Ð10
HiMidG -12Ð12 dB
HiMidF 200Ð8000 Hz
HiMidQ 0.3Ð10
HiType Shlv, Peak
HiG -12Ð12 dB
HiF 1.4Ð20.0 kHz
HiQ 0.3Ð10
Level -60Ð12 dB
EQA/EQB (Equalizer channel A / channel B)
Turn the equalizer on/off. When this is turned off, the fol-
lowing items will not be displayed.
InputG (Input gain)
Adjust the overall volume level of the sound before it enters
the equalizer.
LowType (Low type)
Select the type of the low range equalizer.
Shlv: Shelving type
Peak: Peaking type
LowG (Low gain)
Specify the gain (amount of boost/cut) for the low range
equalizer.
LowF (Low frequency)
Specify the center frequency of the low range equalizer.
Equalizer
Equalizer
Input A
Input B
Output A
Output B
Link
Chapter 1 Trying out the expanded functions
26
