Optional Functions

132

Changing the Drum Size

To save costs on master rolls and ink,
you can shorten the length of each
master by changing to an optional
smaller drum.

Printing Area (At 23

°°°°C/73°°°°F,

65% RH)

❖

❖ Metric version

❖

❖ Inch version

Master Cut Length

A3 drum…320mm

× 530mm, 12.5" ×

20.9", 255 masters/roll
11"

× 17" drum…320 × 540mm, 12.5" ×

21.3", 245 masters/roll
O p t i o n a l A 4 , 8

× 1 1 "

drum…320mm

× 325mm, 12.5" ×

12.8", 410 masters/roll

Note

❒ For changing the drum unit, ⇒

A3 drum

More than 290

× 410mm,

11.4"

× 16.2"

A4 drum

More than 290

× 200mm

11"

× 17"

drum

More than 290

× 420mm,

11.4"

Ч 16.6"

Ч 11"

drum

More than 11.4"

Ч 7.8"
