Installing the PostScript Printer Driver
42
6
❒ We recommend that you upgrade your Windows NT4.0 operating system to
the latest version before installing the printer driver. Contact your Windows
retailer for details about the latest version available.
❒ Be sure to install the PPD file for Windows NT4.0. Do not accidently install
the PPD file for Windows 95/98.
A
Close all applications that are currently running.
B
Click [Start] on the task bar, point to [Settings] , and then click [Printers] .
The [Printers] window opens.
C
Double-click the [Add Printers] icon.
The [Add Printer Wizard] starts up.
D
After confirming the [My Computer] option is selected, click [Next] .
A dialog for selecting the printer port appears.
E
Check the check box of the port you want to use, and then click [Next]
A dialog for selecting the printer manufacturer and model appears.
F
Click [Have Disk] .
A dialog for installing the driver from a disk appears.
G
Insert the CD-ROM that comes with your printer into your computer's CD-
ROM drive.
H
Change the drive name in the list box to the name of the CD-ROM drive,
and then click
[Browse] .
I
In the [Folders:] box, double-click [PS] and [WINNT4] . Then double-click the
folder of the appropriate language for your operating system. Finally, click
[Open] .
J
Click [OK] .
A printer model selection dialog appears.
K
Select the name of the printer whose driver you want to install by clicking
it, and then click
[Next] .
A dialog for changing the printer name appears.
L
Change the name of the printer, if you want, and then click [Next] .
M
Click [Next] .
N
In the next dialog asking if you want to print a test page, select [No] and
then click [Finish] .
The installer copies the printer driver files from the CD-ROM to your comput-
er's hard disk.
