Configuring the Printer for the Network with the Operation Panel
26
3
Setting Up the IP Parameters
After installing the optional network
interface board, configure it for the
network using the printer's operation
panel.
Reference
P.16 “Type 1 Printer: Installing
the Network Interface Board Type
2000”
P.22 “Type 2 Printer: Installing
the Network Interface Board Type
2000”
A
Press
{
Menu
}.
The following message appears on
the panel display.
Main Menu: j
Job Control l
B
Press
{T}{U} until the following
message appears.
Main Menu: j
Host Interfacel
C
Press
{
Enter
}.
The following message appears on
the panel display.
Host Interface:j
1.Printer Lang.l
D
Press
{T}{U} until the following
message appears.
Host Interface:j
1.Network Setupl
E
Press
{
Enter
}.
The following message appears on
the panel display.
Network Setup: j
1.IP Address l
F
Press
{
Enter
}.
The current IP address appears on
the panel display. A pointer (k)
blinks on the value to be specified.
IP Address: jld#
000.000.000.000
G
Specify the first (leftmost) 3 digits
of the IP address using
{U} {T}.
Use
{U} to increase a value, and
{T} to decrease.
IP Address: jld#
100.000.000.000
H
Press
{
Enter
}.
A pointer (k) moves to the second
3 digits.
Note
❒ Before pressing
{
Enter
}, you can
return the pointer (k) to the pre-
vious (left) 3 digits by pressing
{
Escape
}.
❒ If you press
{
Escape
} when the
pointer (k) is on the leftmost 3
digits, the specified IP address
is canceled and you can return
to the previous panel display.
I
Repeat steps
G and H to specify
the rest of the digits of the IP ad-
dress.
J
Check if the pointer (k) is at the
rightmost digit, press
{
Enter
} to
