NWSetup:NetWare Print Server Configuration
9
2
C
Click on [Next] to continue.
The “Port 1” screen appears.
Creating and Adding the Print Queues
Most of the fields will be configured automatically.
Edit the following fields with the appropriate information.
⇒
Refer to online help for additional information about the fields on this screen.
A
From the Port 1 screen.
❖ ❖ ❖ ❖ Enable Printer box
Click to place a check in this box. If it is not checked, the remaining screens
will not be enabled.
❖ ❖ ❖ ❖ Printer Name
The name of the printer. Note: this is a read only field.
❖ ❖ ❖ ❖ Queues Serviced by Printer
This field contains a list of queues that are serviced by the printer.
B
Click on [Add Queue] to add a queue.
The Add Queue to Printer screen appears.
❖ ❖ ❖ ❖ Connection/Server
This list menu is used to select a server connection.
❖ ❖ ❖ ❖ Context
This field allows you to specify an NDS context for the queue.
❖ ❖ ❖ ❖ Queue
Lists all of the queues available on the currently selected connection.
C
Click on [Create Queue] to create a new queue.
The Create Queue screen appears.
❖ ❖ ❖ ❖ Queue Name
Input the name of the new queue.
❖ ❖ ❖ ❖ File Server Volume
The volume in which the queue will be created.
❖ ❖ ❖ ❖ NDS Context
The context in which the queue will be created.
D
Click on [OK] to finish creating the new queue.
Return to the Add Queue to Printer screen.
