NComputing PC Expanion L120 - Manual (Page 58)

8-17
Click the icon in the ‘UTMA/UTSA Setup
view.’ 2
Select either ‘TS 2’ or ‘TS 3’ from the ‘Host Computer List to Connect
to,’ click the button and then click the button. To
connect to a specified host computer automatically, there must be
one host computer in the list on the PC
Expanion’s initial screen. If ‘Autodetection’ is selected in the ‘Host
Computer List to Connect to,’ select ‘Autodetection’ and click the
button to unselect the option. Then select either
‘TS 2’ or ‘TS 3’. 3
Input the IP address of the host PC in the “Terminal Server network
address” column of “Edit Connection Profile” window. Then click the
button. Refer to ‘3. How to check the IP address setting of host
PC” in Part 8. 4
Select the host PC that the PC Expanion is connected to automatically in
the “Auto-Connect” list. Click the button or the button. 5
