NComputing PC Expanion L120 - Manual (Page 55)

8-14
Enter the IP address of the host computer to connect to the Terminal
Server network address field. For the IP address of a host computer, refer
to ‘3. Setting and Confirming the IP Address of a Host Computer.’ If the
IP address is incorrect, the host computer will not be connected. Click
the button to save the settings and click the button to
exit the settings. 3
Click the arrow in the PC Expanion’s initial screen
and select a host computer from the list. If ‘Autodetection’ is not
selected and ‘TS 2’ or ‘TS 3’ is selected, ‘TS 2’ or ‘TS 3’ appears in the list
without the ‘*’ symbol. 4
Click the button. When the
Windows logon screen appears, type the
user ID and the password. 5
How to map the PC Expanion and connect to the host PC under the NCT-2000-XP console
Select
in order to run the program. Go to the
.
Select the specific PC Expanion and then double-click it.
1
Click the icon in
the ‘UTMA/UTSA Setup view.’ 2
Select ‘TS 2’ or ‘TS 3’ in the connection list
and then click the button. Click
the button and view the setup
host computer information. If
‘Autodetection’ is selected, up to 8 host
computers within the same sub-network
of the NCT-2000-XP application are
automatically found and listed. 3
