2-37

CD-ROM Drive

NEC Express5800/ft series has a CD-ROM drive on the front panel. It is a device used to read data
from a CD-ROM (compact disc read-only memory). Compared to a floppy disk, a CD-ROM allows
for larger volume and fast data readout.

CAUTION


Observe the following instructions to use the server safely. There are risks of a
burn, injury, or damage to physical assets. For details, see PRECAUTIONS
FOR SAFETY in Chapter 1.

Do not leave the CD tray ejected.

About the CD-ROM Drive of NEC Express5800/ft series

Two CD-ROM drives (one on each PCI module) are mounted on NEC Express5800/ft series. Both
CD-ROM drives are available after the OS startup. When installing from the Back Up CD-ROM,
only the CD-ROM drive mounted to the primary PCI module can be used for installation.

When you cannot eject a CD-ROM

When you cannot eject the CD-ROM by pressing the eject button, follow the steps below to eject it:

14.

Perform the shutdown process of the Linux for Express5800/ft series. Then press the
POWER switch to turn off the power of the NEC Express5800/ft series.

15.

Use a metal pin of about 1.2 mm in diameter and 100 mm long (alternatively, you can use
a fairly large paper clip after straightening). Insert it gently into the manual release hole
located to the right of the eject button until the tray is ejected.

IMPORTANT:

Do not use a toothpick, plastic pin, or other breakable objects.

If you cannot eject the CD-ROM by following the steps above, contact your
sales agent.

16.

Hold the tray and pull it out.

17.

Take out the CD-ROM.

18.

Push the tray back.

Manual release hole
