2-20

PCI#1 PCI#2

Status

LED 2

DISK

Access

LED

Status

LED 2

DISK

Access

LED

Description Action

Green Green/

Off

*

Amber Green/

Off

*

i) There is an error in
the option PCI board or
the PCI module board
connected or mounted
on PCI module 1.
ii) There is an error in
the devices connected
to the option PCI board
connected or mounted
on PCI module 1.
(including the cable
disconnection)
iii) The LAN cable
connected or mounted
on PCI module 1 is
disconnected.

Make sure that the option PCI
board is properly mounted and
cables are properly connected
to the connecters of the PCI
module or the option PCI
board.
Remount the PCI module 1.
If the problem persists, contact
your sales agent.

Amber Green/

Off

*

Green Green/

Off

*

i) There is an error in
the option PCI board or
the PCI module board
connected or mounted
on PCI module 2.
ii) There is an error in
the devices connected
to the option PCI board
connected or mounted
on PCI module 2
(including the cable
disconnection)
iii) The LAN cable
connected or mounted
on PCI module 2 is
disconnected.

Make sure that the option PCI
board is properly mounted and
cables are properly connected
to the connecters of the PCI
module or the option PCI
board.
Remount the PCI module 2.
If the problem persists, contact
your sales agent.

Amber Amber Green Green/

Off*

Green Green/

Off*

Amber Amber

DISK is performing
mirroring.

Wait for the mirroring to be
completed.

* DISK ACCESS LED illuminates green when hard disk is accessed.

Tips:

When the Status LED 1 is off, the colors of the Status LED 2 indicate the followings.

You must be careful especially when detaching modules.

- Green: Unmounting the module has no effect on the system operation.
- Amber: Unmounting the module causes a system down.
