7-4
STATUS LED
Indication
Color State
Suspected
module
Explanation Procedure
= A =
AmbientTempAlm
00 Amber Blink CPU module Temperature alarm (lower
limit)
AmbientTempAlm
02 Amber Lit CPU module Fatal temperature alarm
(lower limit)
AmbientTempAlm
07 Amber Blink CPU module Temperature alarm (upper
limit)
AmbientTempAlm
09 Amber Lit CPU module Fatal temperature alarm
(upper limit)
Contact your sales agent.
= B =
BMC Unsync - - PCI module #1 The BMC cannot be
synchronized. Contact your sales agent.
BMC0 Not Ready Green Blink PCI module #1
BMC1 Not Ready Green Blink PCI module #2 PCI module’s BMC is
disconnected If disconnection continues
for a while, contact your
sales agent.
= C =
Cor0 +12vAlm 00 Amber Blink PCI module #1 12-V power voltage alarm
(lower limit)
Cor0 +12vAlm 02 Amber Lit PCI module #1 Fatal 12-V power voltage
alarm (lower limit)
Cor0 +12vAlm 07 Amber Blink PCI module #1 12-V power voltage alarm
(upper limit)
Cor0 +12vAlm 09 Amber Lit PCI module #1 Fatal 12-V power voltage
alarm (upper limit)
Cor0 +2.5vAlm
00 Amber Blink PCI module #1 2.5-V power voltage alarm
(lower limit)
Cor0 +2.5vAlm
02 Amber Lit PCI module #1 Fatal 2.5-V power voltage
alarm (lower limit)
Cor0 +2.5vAlm
07 Amber Blink PCI module #1 2.5-V power voltage alarm
(upper limit)
Cor0 +2.5vAlm
09 Amber Lit PCI module #1 Fatal 2.5-V power voltage
alarm (upper limit)
Cor0 +3.3vAlm
00 Amber Blink PCI module #1 3.3-V power voltage alarm
(lower limit)
Cor0 +3.3vAlm
02 Amber Lit PCI module #1 Fatal 3.3-V power voltage
alarm (lower limit)
Cor0 +3.3vAlm
07 Amber Blink PCI module #1 3.3-V power voltage alarm
(upper limit)
Cor0 +3.3vAlm
09 Amber Lit PCI module #1 Fatal 3.3-V power voltage
alarm (upper limit)
Cor0 +3.3vsAlm
00 Amber Blink PCI module #1 3.3-V power voltage alarm
(lower limit)
Cor0 +3.3vsAlm
02 Amber Lit PCI module #1 Fatal 3.3-V power voltage
alarm (lower limit)
Cor0 +3.3vsAlm
07 Amber Blink PCI module #1 3.3-V power voltage alarm
(upper limit)
Cor0 +3.3vsAlm
09 Amber Lit PCI module #1 Fatal 3.3-V power voltage
alarm (upper limit)
Cor0 +5.0vAlm
00 Amber Blink PCI module #1 5-V power voltage alarm
(lower limit)
Cor0 +5.0vAlm
02 Amber Lit PCI module #1 Fatal 5-V power voltage alarm
(lower limit)
Cor0 +5.0vAlm
07 Amber Blink PCI module #1 5-V power voltage alarm
(upper limit)
Contact your sales agent.
