NEC Express 5800/320Lb User Manual
Page 280
8-38
7.
Align the terminal segment of the board with the connection of the slot and insert the
board slowly into the slot.
TIPS:
Check to see if the edge of the bracket (taper) is inserted into a slot of the
chassis. In the case of a long board, check also to see if its other edge is inserted into
the bracket guide.
Guide
Slots for inserting
bracket edges
