4-35
Selectable Boot Settings
If you put the cursor on "Selectable Boot Settings" with keyboard cursors (
↓ and ↑) in the
"Configuration Settings" menu and press Enter, the screen for setting the information on the start
from the device connected to the host adapter appears.
Submenu item Parameter
Description
Selectable
SCSI Boot
Enabled
[Disabled]
Specify whether the boot from SCSI device can be
selected or not.
SCSI Bus
[0]
1
Select the bus to which the started SCSI device is
connected.
SCSI Boot ID
[0], 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13,
14, 15
Set the SCSI ID of the started SCSI device.
SCSI Boot Lun
[0], 1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13,
14, 15
Select the number of the LUN to which the started
SCSI device is bound.
[ ]: Factory-set
Restore Default Settings
If you put the cursor on "Restore Default Settings" with keyboard cursors (
↓ and ↑) in the
"Configuration Settings" menu and press Enter, the display changes to the screen for returning the
setting values to the default values.
IMPORTANT:
The default values can be restored for each SCSI bus.
Raw Nvram Data
If you put the cursor on "Raw Nvram Data" with keyboard cursors (
↓ and ↑) in the "Configuration
Settings" menu and press Enter, the information on NvRAM installed in the host adapter is
displayed in the hexadecimal format.
This function is provided to solve problems. The information cannot be edited.
