5-61

Connect from the Management PC Directly Linked (through Serial port B)

On the management PC that is linked directly to Serial port B of the main unit, perform the steps
below:

112.

Start the management PC where MWA is installed. From the Start menu, select [Program]
→ [NEC MWA] → [MWA].

When MWA starts, the initial screen “Remote Control Manager” will appear.

113.

Select [Environment] – [Direct Connection Setting] from the [File] menu of NEC MWA
to display the [Direct Connection] dialog box. Configure the following settings:


Port No.:

COM port on the management PC to be connected

Baud Rate:

19200

Flow Control: None

114.

From MWA’s [File] menu, select [Configuration] command to open [Configuration]
dialog box.

115.

Select [New] to display [Select a model] dialog box.

116.

Check [Write to FD] and select an applicable model to open [Configuration for ft Series]
dialog box.

Ex)

The model name is printed on the front cover like “NEC Express5800/320Lb,”

or “NEC Express5800/320Lb-R.”

117.

[Configuration for ft Series] dialog box, specify/register configuration information
including the names of computers to be managed, and then write the information to FD as
the following filename:

CSL_LESS.CFG

118.

Right-clicking the server name to open the pop-up menu and select [Property] command
to open [Property] dialog box.

119.

When [Property] dialog box appears: specify the items as follows:

<[ID] page>
Connection mode:

COM

COM:

Direct (cross cable)

120.

Right-clicking the server name to open the pop-up menu and select [Open Remote
Console] to open [MWA Remote Console].

After checking to see if the server window is open on [MWA Remote Console], click the
[Connect] button.

121.

Hook up the management PC directly to Serial port B of the computer to be managed.

122.

Insert NEC EXPRESSBUILDER CD-ROM into the drive of the managed computer and
insert the floppy disk storing the configuration information (CSL_LESS.CFG) into the
FDD drive.
