CS 1000 SIP configuration and UDP location dialing 53
Configuring HLOC is necessary to properly handle a UDP number sent
by the MCS 5100 based on the Private Charge ID of the MCS 5100 user
profile. The MCS 5100 always qualifies this number as a UDP number.
HLOC will already have been configured if UDP is used. Even if only CDP is
used, you must still configure HLOC.
LD 90 Configure Home Location Code (HLOC).
Prompt Response Description
REQ NEW Add new data.
CUST xx Customer number as defined in LD 15.
FEAT NET Network translation tables
TRAN AC1 or AC2 Translator
TYPE HLOC Home Location Code.
Note: HLOC must match what MCS 5100 is sending.
HLOC 334 Home Location code.
DMI 1-255 Digit Manipulation Index numbers
Note: DMI range is dependent on which Package is used.
(0) No digit manipulation required
(0)-31CDP
(0)-255 NARS and BARS
(0)-999 NARS and BARS with FNP
DMI is only prompted when the Directory Number
Expansion (DNXP) package 150 is equipped and SDRR =
LDID.
The maximum number of Digit Manipulation tables is
defined by prompt MXDM.
Configuring AC1 or AC2 is necessary to properly handle a UDP number
sent by the MCS 5100 based on the Private Charge ID of the MCS 5100
user profile. The MCS 5100 always qualifies this number as a UDP number.
AC1 or AC2 will already have been configured if UDP is used. Even if only
CDP is used, you must still configure AC1 or AC2.
LD 86 Configure Access Code (AC1 or AC2).
Prompt Response Description
REQ CHG Change existing data block.
CUST xx Customer number as defined in LD 15.
FEAT ESN Electronic switched network
