master HS module
rear panel features
insert points—left, right, and mono
Separate 1/4" TRS jacks provide the ability to insert external signal proces-
sor into the signal paths of the left, right and mono MASTERS .
insert sends—left, right, and mono
These jacks connect to the input of signal processors.The sig-
nals are ground compensated.
insert returns—left, right, and mono
These jacks connect to the outputs of a signal processors.They
can accept balanced or unbalanced signals.
Midi In, Midi Out
These jacks allow the MICROPROCESSOR MUTE SYSTEM to be linked into a MIDI
system.Program changes and certain system-exclusive tasks can be carried
out.
see—microprocessor mute system
midi-in
M
IDI information is brought into the console and routed to the MICRO -
PROCESSOR MUTE SYSTEM .
midi-out
M
IDI information sent out by the MICROPROCESSOR MUTE SYSTEM is available
at this connector.
DC power-in
This jack connects the power supply cable to the console.
5
Plugging a 1/4" plug
into this jack does not
break the internal signal
flow of the respective left,
right, and mono masters.
+
Plugging a 1/4" plug
into this jack breaks
the signal flow
of the respective left, right,
and mono masters.
+
