master HS module
local monitor output features
talkback mono
—TALK TO MONO
The
TALKBACK
system output is added to the mono
MASTER
output.
The level of the
TALKBACK
signal is set by the
TALKBACK
level control in the
MASTER
section.
main left/right to mono—
L/R TO MONO
The
MAIN
left and right post-fader signals are summed together as a
mono signal and are routed to the mono bus.The summed left and right
signals automatically combine with any signals that are assigned directly to
the mono bus to make up the mono output.
The mono output consists exclusively of signals assigned directly to
the mono bus. Signals that appear at the
MAIN
left and right faders do not
appear at the mono output.
signal/peak
LED—SIG/PEAK
This dual-color LED responds to the pre-fader mono signal. It illumi-
nates green with varying brightness in proportion to the audio signal.
When the signal approaches clipping, either pre or post fader, the
LED
illu-
minates red.
LED
5
