master RT module
local monitor output features
The local MONITOR output section controls the audio feed for the console
operator. Features are similar to those of ALT OUT section, except that the
MONITOR section is normally used to access the SOLO system as well as
MAIN outputs.
Like the alternate output section, it provides the ability to assign the left
and right master signals to a designated pair of balanced-male
XLR con-
nectors on the rear-panel.
By utilizing the mode switches located below the local MONITOR output
level control, these signals can be derived in a number of different ways. In
default mode (no switches depressed), the post-fader left and right
MASTER
signals are routed through local MONITOR level control and appear at the
MONITOR OUT balanced-male XLR connectors on the rear-panel.
This feed is replaced by the SOLO signal when a SOLO is activated on the
console.
monitor-out level
This control governs the levels that appear at the MONITOR OUT left
and right balanced XLR connectors on the rear-panel.
sum mono
The signal feeding the MONITOR OUT section are taken before the
MAIN left and right faders.
The signal feeding the MONITOR OUT section are taken after the MAIN
left and right faders.
solo off
When any of the SOLO switches on the console are active, the SOLO
audio is routed in stereo through the MONITOR OUT level control and
appears at the left and right MONITOR OUT balanced-male XLR connectors
on the rear-panel.
This overrides the left and right feed to the MONITOR output.
The MONITOR output is not affected by the SOLO system.
